2.02.002 - Track Switch Motor - Left

Introduction

Motor 2.02.002 is designed to actuate a left turn LEGO® switch.

Manuals

3D Models

Track Switch Motor - Left - Base

Motor base with integrated supports

Part: 2.02.002-1
Revision: v13
Release: 20-JUL-23
File: 2-02-002-1_v13.stl (173.0KB)
Model History

Track Switch Motor - Left - Base

Motor base without supports

Part: 2.02.002-1
Revision: v13
Release: 20-JUL-23
File: 2-02-002-1-nsp_v13.stl (150.3KB)
Model History

Track Switch Motor - Left - Cover

Motor cover with integrated supports

Part: 2.02.002-2
Revision: v13
Release: 20-JUL-23
File: 2-02-002-2_v13.stl (467.0KB)
Model History

Track Switch Motor - Left - Cover

Motor cover without supports

Part: 2.02.002-2
Revision: v13
Release: 20-JUL-23
File: 2-02-002-2-nsp_v13.stl (432.0KB)
Model History

Track Switch Motor - Left - Rack

Motor rack

Part: 2.02.002-3
Revision: v13
Release: 20-JUL-23
File: 2-02-002-3_v13.stl (15.3KB)
Model History

Track Switch Motor - Right - Gear

Motor gear with integrated support

Part: 2.02.001-4
Revision: v22
Release: 28-FEB-21
File: 2-02-001-4_v22.stl (131.5KB)
Model History

Track Switch Motor - Right - Gear

Motor gear without support

Part: 2.02.001-4
Revision: v22
Release: 28-FEB-21
File: 2-02-001-4-nsp_v22.stl (122.2KB)
Model History

Gear Mounting Tool

Tool to mount the gear onto servo

Part: 2.02.001-5
Revision: v22
Release: 28-FEB-21
File: 2-02-001-5_v22.stl (209.3KB)
Model History

Gear Mounting Tool

Tool to remove the servo from the mounting jig

Part: 2.02.001-6
Revision: v22
Release: 28-FEB-21
File: 2-02-001-6_v22.stl (182.9KB)
Model History
