3.01.017 - Diagonal Track

Introduction

Track 3.01.017 is a short diagonal monorail track. It enables building lines that make an angle of 45° with the standard monorail tracks. This track has an equivalent horizonal/vertical length of 8 studs. It's half as long as track 3.01.006.

Length: 11.3 studs
Width: 4 studs

3D Models

Monorail Track

Part: 3.01.017
Revision: v07
Release: 24-JAN-21
File: 3-01-017_v07.stl (328.1KB)
Suggested Print Settings

Platform: 80°C
Extruder: 235°C
Layer Thickness: 0.19mm
Nozzle Diameter: 0.4mm
Support: 20%
Infill: 30%
